This is a free and fast online utility that converts decimal or hexadecimal pixel byte arrays into BMP images. You can use the configuration options (below) to identify the byte notation, select the RGB channel order, and set the bitmap width. Extra options allow you to choose a fill color for incomplete data and enlarge every source pixel into a crisp square block. Created by graphics designers from team Browserling.
This is a free and fast online utility that converts decimal or hexadecimal pixel byte arrays into BMP images. You can use the configuration options (below) to identify the byte notation, select the RGB channel order, and set the bitmap width. Extra options allow you to choose a fill color for incomplete data and enlarge every source pixel into a crisp square block. Created by graphics designers from team Browserling.
This free online browser-based program turns a byte array into a visible BMP image. It groups the input bytes into sets of three, reconstructs one pixel from each set, and draws the pixels row by row from left to right. The bytes can be written as ordinary decimal values, such as "255, 128, 0", or hexadecimal values, such as "ff, 80, 00" and "0xFF, 0x80, 0x00". By default, the automatic mode examines the notation of the input values, determines whether they are decimal or hexadecimal bytes, and decodes them accordingly. Some values, however, are valid in both formats. For example, "10, 20, 30" can represent either decimal or hexadecimal bytes because every value is valid in either notation. In such cases, you can select "Read Decimal RGB Bytes" or "Read Hex Bytes" to tell the program exactly how to interpret the data. The program accepts plain byte lists, one-dimensional arrays, pixel-grouped arrays, row-grouped arrays, and fully nested structures produced by the Convert Bitmap to Byte Array tool. It also accepts custom byte and pixel separators made from punctuation or whitespace. You can use the "Byte Order" option to specify how the three color channels are arranged in every pixel. Select RGB for red-green-blue data, BGR (blue-green-red) for the channel order commonly used in 24-bit BMP pixel storage, or any of the four other channel arrangements. To arrange the decoded pixels into bitmap rows, enter the number of pixels per row in the "Width" option. If the input is already divided into lines or nested rows of the correct length, you can leave the width empty and preserve that existing structure. Any incomplete pixel, as well as any missing position at the end of a shorter row, is replaced with the selected "Fill Color". You can also increase the "Pixel Size" to turn every data pixel into a larger, sharp-edged square, making compact byte-array images easier to view or use as pixel art. Bmp-abulous!
This free online browser-based program turns a byte array into a visible BMP image. It groups the input bytes into sets of three, reconstructs one pixel from each set, and draws the pixels row by row from left to right. The bytes can be written as ordinary decimal values, such as "255, 128, 0", or hexadecimal values, such as "ff, 80, 00" and "0xFF, 0x80, 0x00". By default, the automatic mode examines the notation of the input values, determines whether they are decimal or hexadecimal bytes, and decodes them accordingly. Some values, however, are valid in both formats. For example, "10, 20, 30" can represent either decimal or hexadecimal bytes because every value is valid in either notation. In such cases, you can select "Read Decimal RGB Bytes" or "Read Hex Bytes" to tell the program exactly how to interpret the data. The program accepts plain byte lists, one-dimensional arrays, pixel-grouped arrays, row-grouped arrays, and fully nested structures produced by the Convert Bitmap to Byte Array tool. It also accepts custom byte and pixel separators made from punctuation or whitespace. You can use the "Byte Order" option to specify how the three color channels are arranged in every pixel. Select RGB for red-green-blue data, BGR (blue-green-red) for the channel order commonly used in 24-bit BMP pixel storage, or any of the four other channel arrangements. To arrange the decoded pixels into bitmap rows, enter the number of pixels per row in the "Width" option. If the input is already divided into lines or nested rows of the correct length, you can leave the width empty and preserve that existing structure. Any incomplete pixel, as well as any missing position at the end of a shorter row, is replaced with the selected "Fill Color". You can also increase the "Pixel Size" to turn every data pixel into a larger, sharp-edged square, making compact byte-array images easier to view or use as pixel art. Bmp-abulous!
In this example, we turn a decimal RGB byte array into a Super Mario bitmap sprite. The automatic mode recognizes the decimal byte notation, while the line breaks already divide the array into rows and supply the image width, so the width option stays empty. We set pixel size to 5, enlarging every source pixel into a crisp 5-by-5 block and producing a clean 80-by-160 BMP sprite. (Source: Nintendo.)
In this example, we reconstruct a blue iris bitmap from an array of 0x-prefixed hexadecimal RGB bytes and leave byte-format detection in automatic mode. The 50 inner arrays correspond to the 50 image rows, with 29 pixels in each row, so the nested structure preserves the original layout. We enlarge each source pixel into a 2-by-2 block and produce a 58×100 BMP. (Source: Vecteezy.com.)
In this example, we decode an unusually formatted hex string into a pumpkin BMP. As the input bytes are not divided into rows, we specify the expected bitmap width and reconstruct a 50-by-43 image. The values follow the BGR order commonly used in bitmap files, so we select this order in the options. Choosing another byte order produces an interesting version of the same BMP with shifted colors. (Source: Vecteezy.com.)
